Not reclose unless the ambient temperature drops below -35°C (-31°F) , open on rise (normally closed)
Single pole, single throw (SPST)
One shot action, high reliability, ROHS compliant
Ceramic construction, CTI 250
New:
Operating temp. Range: 0- 270℃, 250V/10A/16A, CQC certified
Caratteristiche
Operating temperature range: 50～230℃ (122～446°F)
Auto reset temp. Below -35℃(-31°F)
Temperature tolerance: ±5.0K, ±8.0K, ±10.0K
Contact resistance: 50mΩor less
Electrical Rating:
Applicazioni
|
Electrical rating |
Agency approvals |
|||||
|
VDE |
UL |
TÚV |
CQC |
Life cycles |
Remarks |
|
|
AC125V/10A |
|
● |
|
|
100 K |
Ceramic |
|
AC125V/16A |
|
● |
|
|
100 K |
|
|
AC250V/10A |
|
|
● |
● |
30 K |
|
|
AC250V/16A |
|
|
● |
● |
30 K |
|
